Double axis construction decoration waste shredder
- Construction waste
- waste soil, spoil, silt
BRIEF DESCRIPTION
APPLICABLE MATERIALS
Features
- The overall cyclic movement of warehouse materials allows unrestricted feeding, ensuring high shredding efficiency and preventing material jamming.
- The main shaft is specially custom-designed with a large rotating diameter to guarantee shredding contact surface and enhance production capacity.
- The transmission components use couplings to reduce vibration, protecting the main shaft and gearbox without power loss.
- Both upper and lower parts of the main shaft are equipped with fixed blades to effectively cut materials, preventing entanglement, and resulting in small shredded particle sizes.
- The electrical control system is PLC programmable, equipped with functions such as start, stop, forward rotation, and automatic overload protection. The entire machine operates automatically, ensuring stable and safe operation, while also saving labor costs.
UNIT INTRODUCTION
Heavy moving knife with high crushing efficiency, sturdy and durable
The moving blade is made of DC53material, while the fixed blade is made of D2 material, which saves labor and has strong cutting force, demonstrating strong crushing ability.
The iron frame plate is thick and can withstand high torque, making it very sturdy
Welding of the main box, tempering and precision processing after welding, to ensure the strength and assembly accuracy of the box.
High spindle strength, strong fatigue and impact resistance
The spindle is made of high-strength alloy steel material, which has undergone multiple heat treatments and high-precision processing. It has good mechanical strength, strong fatigue and impact resistance, and long service life.
Easy to adjust, low maintenance cost, economical and durable
The guide strip and guide block installed in the pushing box are replaceable and adjustable, maintaining stable pushing and sealing of the crushing chamber.
TECHNICAL DATA
Equipment model | power(kw) | input speed(r/min) | Overall dimensions(mm) |
GS-600 | 11-22 | 12-30 | 2800*1400*1900 |
GS-800 | 17-37 | 12-30 | 3700*1540*2200 |
GS-1000 | 30-45 | 7-20 | 3860*1550*2350 |
GS-1200 | 37-55 | 7-20 | 4200*1650*2400 |
GS-1400 | 45-90 | 10-15 | 4100*2250*2850 |
GS-1600 | 55-132 | 7-15 | 4100*2250*2850 |
GS-2000 | 75-200 | 7-12 | 6000*2800*2900 |
